MAIN TECHNICAL DATA:

Table size 2500 x 1300mm
Number of tables 2
Number of daylights 1
Front side (loading) 2500mm
Loading depth 1300mm
Loading height 1130mm
Daylight between the platens 300mm
Number of cylinders 8
Cylinder formation 4 rows of 2 cylinders each
Cylinder diameter 85mm
Cylinder stroke 400mm
Closing speed 22mm/sec
Total thrust 120 Tonnes
Max specific pressure on 80% of the surface 3.5kg/cm² (50psi)
Max specific pressure on 100% of the surface 2.8kg/cm² (40psi
Working temperature 0 - 130°C
Oil pump motor 5.5kw
Net weight 6500 Kg
Automatic Opening with Timer
Manual Exclusion of 2 Cylinders

All equipment according to CE regulations.

Lease or Finance options are available on request.
