o All welded frame, with all four sides open, allowing loading from any position
o Two 9.1kw electric platens each with their own combined temperature indicator and controller
o Contact pressure manometer maintains the required pre-set pressure during the pressing cycle
o Fast cycle times can be achieved with pressing time set on an electric timer with audible warning
o Opening and closing is by means of push-button control
o Parallel movement of press table ensured by means of rack and pinion mechanism
o Safety kick wire encircling base of the machine will stop the press instantly if activated.
o The added value benefits, design and quality performance provide excellent value for money.

Technical Specification: 8' x 4'

Max.  Pressing Area 2500 x 1300mm
Total Thrust 85 tonnes
Max.  Pressure over full platen area 2.6kg/cm
Max.  Pressure over 2/3 area 3.9kg/cm
Number of Rams 8 x 85mmØ
Maximum Daylight 300mm
Working Height 1040mm
Hydraulic Power Pack 7.5kw
Closing Speed per mm per Second 20
Overall Dimensions (LxWxH) 3400x1650x1930mm
Net Weight 3500kg

Lease or Finance options are available on request.
